Creating an Appliance Garage with a Tambour Door


Reference Number: KB-02072
Last Modified: July 20, 2021

The information in this article applies to:

Chief Architect Premier or Chief Architect Interiors



QUESTION

I need to create an appliance garage with a vertical sliding tambour door in my cabinet. Is there a way to do this in Chief Architect?

Appliance garage inserted into a corner cabinet


ANSWER

You can change the door style of any cabinet using a selection of pre-made doors located in the Library Browser.

In this article, we will add a bread door, also known as a tambour door, to a wall cabinet using a door style located in the Chief Architect Core Catalogs.


To create an appliance garage with a tambour door

  1. Start by adding a wall cabinet to your plan by going to Build> Cabinet> Wall Cabinet . When moving the cursor into a corner, notice that the temporary preview will update to reflect a corner wall cabinet with a diagonal door. Click to place the the cabinet.

    Corner wall cabinet placed in a floor plan


  2. Using the Select Objects  tool, click on the wall cabinet, then select the Open Object edit button.


  3. On the General panel of the Wall Cabinet Specification dialog that opens, adjust properties such as the Left/Right Side Widths, Height, and Finished Floor to Top/Bottom values to your liking.

    In this example, the Left and Right Side Widths are set to 24", the Height is set to 18", and the Finished Floor to Top is set to 54".

    General panel of the Wall Cabinet Specification dialog


  4. On the Box Construction panel, change the Door/Drawer Overlay to Inset with a Clearance of 0.

    Starting in X13, the top and bottom of a cabinet can be toggled on/off. If you'd like to remove the bottom of the cabinet, select the No Bottom option.


  5. On the Front/Sides/Back panel:

    Front/Sides/Back panel of the Wall Cabinet Specification dialog


    • Select the 1 Blank Area option in the Face Items list, then click the Delete button. Do the same for the 3 Separation - Horizontal option to remove it from the cabinet.

    • Next, click on the 2 Door - Auto Right option to select it, then change the Item Type to Door - Panel using the drop-down menu.

    • Click the Specify button next to Appliance/Door/Drawer.

    • In the Door Face Item Specification dialog, click the Library button.

      Door Face Item Specification dialog

    • In the Select Library Object dialog that opens next, browse to Chief Architect Core Catalogs> Architectural> Cabinet Doors, Drawers, & Panels> Specialty Storage, choose Appliance Garage, then click OK.

      Select Library Object dialog where the Appliance Garage door style is located

    • Click OK once again to return to the Wall Cabinet Specification dialog.


  6. On the Moldings panel, remove any moldings that you don't want applied to the appliance garage, especially in the case where another wall cabinet will be placed on top.


  7. Make any other desired modifications to the cabinet, such as to the Materials, then click OK.


  8. Take a Camera  view to see the results.

    Camera view of an appliance garage with a tambour door

    You may also find it easier to place a corner cabinet on top of the appliance garage while you're in a camera view.
